Moraine is Salsa's light electric mountain bike. It adds range, route options, and capability to every trail ride with a Fazua Ride 60 drive system and 145 mm of Split Pivot suspension. Moraine's geometry feels right at home on backcountry lines and buffed-out flow trails. Add Salsa’s on-bike cargo features, and Moraine makes riding to the trailhead, sessioning lines, and taking second laps feel like second nature.
- 6061-T6 aluminum frame
- 145mm of Split Pivot suspension to maximize traction and efficiency
- Split Pivot + frame design philosophy allows riders to swap between travel classes
- Fazua Ride 60 class 1 mid-drive motor (20 mph/32 kph max assist)
- 60Nm max torque
- 430Wh Fazua Energy 430 removable internal battery
- Compatible with 210 Wh Fazua Energy range-extender battery (sold separately)
- Fazua LED Hub on top tube for battery status and riding modes
- Fazua Ring Control for easy ride mode selection
- Internal cable and hose routing
- 12 x 148mm Boost rear spacing
- SRAM UDH compatible
- Accommodates up to 29 x 2.5" or 27.5 x 2.7" tires
- Integrated tool and tube strap location in front triangle
- Pump mount location
- All sizes fit one bottle or Fazua Energy range-extender battery
- Frame protection on downtube, main pivot, seatstay, and chainstay
- Meets UL 2849, and UL 2271 certification
Manufacturer Salsa
Manufacturer Part Number 06-003339
UPC 657993353660
Model Salsa Moraine Cues 10 Ebike - Coffee Black
Rear Axle
12mm Thru x 148mm
Throttle
No
TT (Effective)
612
Brake Type
Disc
Removable Battery
Removable for Service
Battery Power (Wh)
430
Battery Power (V)
43.2
Battery Power (Ah)
10
Fork Type
Suspension
Lights Included
No
Frame Material
Aluminum
Frame Type
Suspension
Front Axle
15mm Thru x 110mm
Drive Type
Mid-Drive
Ebike Class
1
Charger Included
Yes
Color
Coffee Black
Battery
Li-Ion
Assist Levels
3
Range Estimate (Mi)
40
Motor Torque (Nm)
60
Charge Time (h)
3.5
Mfg Size
Medium
Assist Speed (Mph)
20
Walk Assist
Yes
Platform
Moraine
Wheel Size
29"
Defined Color
Black
